| 皮带宽(mm) | 输送长度/功率(m/kW) | 输送速度(m/s) | 输送量(t/h) | ||
| 400 | ≤12/2.2 | 12-20/2.2-4 |
20-25/3.5-7.5 |
1.25-2.0 |
30-60 |
| 500 | ≤12/3 | 12-20/3-5.5 |
20-30/5.5-7.5 |
1.25-2.0 |
40-80 |
| 650 | ≤12/4 | 12-20/4-5.5 |
20-30/5.5-11 |
1.25-2.0 |
80-120 |
| 800 | ≤10/4 | 10-15/4-5.5 | 15-30/5.5-15 | 1.25-2.0 | 120-200 |
| 1000 | ≤10/5.5 | 10-20/5.5-11 | 20-40/11-22 | 1.25-2.0 | 200-320 |
| 1200 | ≤10/7.5 | 10-20/7.5-15 |
20-40/15-30 |
1.25-2.0 |
290-480 |
| 1400 | ≤10/11 | 10-20/11-22 |
20-40/22-45 |
1.25-2.0 |
400-680 |
| 1600 | ≤10/15 | 10-20/22-30 | 20-50/30-75 | 1.25-2.0 | 600-1080 |
